Description
Output Power Parameters
-
Wattage
60 W
-
Voltage
24 VDC
-
Current Rating
0 to 2.5 A
-
Ripple and Noise
150 mVp-p
-
Voltage Adjustment Range
21.6 to 29 VDC
-
Setup/Rise Time at Full Load
500 ms, 50 ms at 230 VAC
500 ms, 50 ms at 115 VAC -
Typical Hold Up Time at Full Load
30 ms at 230 VAC
12 ms at 115 VAC
Input Power Parameters
-
Voltage Range
100 to 240 VAC (50 to 60 Hz)
120 to 370 VDC -
Typical Efficiency
90%
-
Typical Current
0.8 A @ 230 VAC, 1.2 A @ 115 VAC
-
Inrush Current (cold start)
60 A @ 230 VAC, 30 A @ 115 VAC
Overload Protection
-
Rated Output Power
105 to 160%
-
Protection Type
Constant current limiting, recovers automatically after fault condition is removed
Overvoltage Protection
-
Overvoltage Range
30 to 36 V
-
Protection Type
Shut down operating voltage, repower on to recover
Physical Characteristics
-
Housing
Plastic
-
Dimensions
52.5 x 90 x 54.5 mm (2.07 x 3.54 x 2.15 in)
-
Weight
230 g (0.5 lb)
Environmental Limits
-
Operating Temperature
-30 to 70°C (-22 to 158°F)
-
Max. Operating Temperature at Full Load
45°C (113°F)
-
Storage Temperature (package included)
-40 to 85°C (-40 to 185°F)
-
Ambient Relative Humidity
20 to 90% (non-condensing)
Standards and Certifications
-
Safety
UL 508
EN 62368-1
UL 62368-1
IEC 62368-1 -
EMC
EN 55032/35
EN 61000-3-2 Class A
EN 61000-3-3
EN IEC 61204-3
EN IEC 61000-6-2 -
EMS
IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
IEC 61000-4-4 EFT: Power: 2 kV
IEC 61000-4-5 Surge: Power: 4 kV
IEC 61000-4-6 CS: 0.15 kHz to 80 MHz: 10 Vrms
IEC 61000-4-8 PFMF: 30 A/m
IEC 61000-4-11
MTBF
-
Time
927,560 hrs
-
Standards
MIL-HDBK-217F
